Pair 1 |
Blue/White w/Co-Extruded Blue Stripe on White Single |
|
Pair 2 |
Orange/White w/Co-Extruded Orange Stripe on White Single |
|
Pair 3 |
Green/White w/Co-Extruded Green Stripe on White Single |
|
Pair 4 |
Brown/White w/Co-Extruded Brown Stripe on White Single |
|
Frequency |
Impedance |
Return Loss |
Attenuation |
NEXT |
ELFEXT |
PS NEXT |
PS ELFEXT |
|
MHz |
ohm |
dB |
dB |
dB |
dB |
dB |
dB |
|
1 |
100+15 |
17 |
2.0 |
62.3 |
61 |
62.3 |
61 |
|
4 |
20 |
4.1 |
53.3 |
49 |
53.3 |
49 | |
|
10 |
22 |
6.5 |
47.3 |
41 |
47.3 |
41 | |
|
16 |
20 |
8.2 |
44.2 |
37 |
44.2 |
37 | |
|
20 |
20 |
9.3 |
42.8 |
35 |
42.8 |
35 | |
|
31.25 |
18 |
11.7 |
39.9 |
31 |
39.9 |
31 | |
|
62.5 |
16 |
17.0 |
35.4 |
25 |
35.4 |
25 | |
|
100 |
15 |
22.0 |
32.3 |
21 |
32.3 |
21 |
