SECURITY CABLE 22AWG/8C STRAND
1) Description
22 gauge (19X0.16mm/7X0.25mm) 8 strand bare copper conductor;
PVC insulation, ripcord, PVC jacket
Application: Commercial audio, Security systems, Power limited control,
Sound & audio, Intercom/PA systems, Broadcast and Nurse call
2) Physical Dimensions
Center Conductor:19X0.16+0.005mm Solid Bare Copper
7X0.25+0.005mm Solid Bare Copper
Insulation:1.10+0.02mm PVC
Insulation Thickness:0.18mm
Ripcord:YES
Jacket:4.35+0.03mm PVC
Jacket Thickness:0.38mm
3) Mechanical Specification
Operating Temperature Range:-20℃ To +75℃
Cable Weight:23.30 Lbs/Mft
Min. Bend Radius:1.7 in.
4) Electrical Characteristics
Operating Voltage:300 VRMS
Max. Conductor DCR:17.0Ω/Mft
Capacitance:14 pF/ft
