Physical Dimensions:
|
Component |
Material |
5D |
7D |
8D |
10D |
12D |
|
Center Conductor |
BC(mm) |
1.80 |
2.60 |
2.80 |
3.50 |
4.40 |
|
Dielectric |
Solid PE(mm) |
5.0 |
7.30 |
7.80 |
10.00 |
12.40 |
|
First Shield |
Bonded AL Foil |
100% |
100% |
100% |
100% |
100% |
|
Second Shield |
TC(mm) |
16X5X0.16 |
16X5X0.16 |
16X5X0.16 |
16X5X0.16 |
16X5X0.16 |
|
Jacket |
PVC(mm) |
7.50 |
8.20 |
8.80 |
13.00 |
15.60 |
|
Frequency (MHz) |
5D |
7D |
8D |
10D |
12D |
|
100MHz |
6.3 |
4.1 |
4.3 |
3.2 |
2.7 |
|
150MHz |
7.8 |
5.1 |
5.3 |
4.0 |
3.4 |
|
280MHz |
10.8 |
7.1 |
7.3 |
5.6 |
4.7 |
|
350MHz |
12.1 |
8.1 |
8.3 |
6.3 |
5.3 |
|
400MHz |
13.0 |
8.7 |
9.1 |
6.8 |
5.7 |
|
800MHz |
18.9 |
12.9 |
13.1 |
10.2 |
8.5 |
|
900MHz |
20.2 |
13.8 |
14.2 |
11.0 |
9.1 |
|
1200MHz |
23.7 |
16.3 |
16.7 |
13.1 |
10.8 |
|
1500MHz |
26.8 |
18.6 |
19.0 |
15.0 |
12.3 |
|
1800MHz |
29.7 |
20.8 |
21.1 |
16.8 |
13.7 |
|
1900MHz |
30.6 |
21.5 |
21.8 |
17.4 |
14.2 |
|
2000MHz |
31.5 |
23.5 |
22.5 |
18.8 |
14.9 |
|
2200MHz |
33.3 |
23.5 |
23.8 |
18.8 |
14.9 |
|
2500MHz |
35.8 |
25.4 |
25.7 |
20.5 |
16.6 |
