Pair 1 |
Blue/White w/Co-Extruded Blue Stripe on White Single |
|
Pair 2 |
Orange/White w/Co-Extruded Orange Stripe on White Single |
|
Pair 3 |
Green/White w/Co-Extruded Green Stripe on White Single |
|
Pair 4 |
Slate/White w/Co-Extruded Slate Stripe on White Single |
|
Pair 5 |
Brown/White w/Co-Extruded brown Stripe on White Single |
|
Pair 6 |
Blue/Red w/Co-Extruded Blue Stripe on Red Single |
|
Frequency
MHz |
Max. Attenuation dB/100m |
Near End Cross Talk
dB |
Min SRL dB |
Fitted Impedance
Ohms |
|
1 |
7.8 |
41 |
12.0 |
100+/-15% |
|
4 |
17.0 |
32 |
12.0 |
100+/15% |
|
8 |
25.9 |
27 |
12.0 |
100+/15% |
|
10 |
30.0 |
26 |
12.0 |
100+/15% |
|
16 |
40.0 |
23 |
10.0 |
100+/15% |
