Pair 1 |
Blue/White w/Co-Extruded Blue Stripe on White Single |
|
Pair 2 |
Orange/White w/Co-Extruded Orange Stripe on White Single |
|
Pair 3 |
Green/White w/Co-Extruded Green Stripe on White Single |
|
Pair 4 |
Brown/White w/Co-Extruded Brown Stripe on White Single |
|
Attenuation |
[@68℉. (20℃)] | ||
|
Frequency (MHz) |
Max. (dB/100 m) |
Frequency (MHz) |
Max. (dB/100 m) |
|
1.0 |
2.0 |
31.25 |
11.7 |
|
4.0 |
4.0 |
62.5 |
17.0 |
|
8.0 |
5.8 |
100.0 |
22.0 |
|
10.0 |
6.5 |
155.0 |
28.1 |
|
16.0 |
8.2 |
200.0 |
32.4 |
|
20.0 |
9.2 |
300.0 |
41.0 |
|
25.0 |
10.4 |
350.0 |
44.9 |
|
Return Loss |
[@68℉. (20℃)] | ||
|
Frequency (MHz) |
Min. (dB/100 m) |
Frequency (MHz) |
Min. (dB/100 m) |
|
1.0 |
20.0 |
31.25 |
23.6 |
|
4.0 |
23.0 |
62.5 |
21.5 |
|
8.0 |
24.5 |
100.0 |
20.1 |
|
10.0 |
25.0 |
155.0 |
18.8 |
|
16.0 |
25.0 |
200.0 |
18.0 |
|
20.0 |
25.0 |
300.0 |
16.8 |
|
25.0 |
24.3 |
350.0 |
16.3 |
|
Frequency
MHz |
Pair to pair |
ACR
(dB/100m)
Min |
Power Sum | |||
|
NEXT
(dB/100m)
Min |
ELFEXT
(dB/100m)
Min |
NEXT
(dB/100m)
Min |
ELFEXT
(dB/100m)
Min |
ACR
(dB/100m)
Min | ||
|
1.0 |
68.3 |
66.8 |
66.3 |
65.3 |
63.8 |
63.3 |
|
4.0 |
59.3 |
54.7 |
55.2 |
56.3 |
51.7 |
52.2 |
|
8.0 |
54.8 |
48.7 |
49.0 |
51.8 |
45.7 |
47.0 |
|
10.0 |
53.3 |
46.8 |
46.8 |
50.3 |
43.8 |
43.8 |
|
16.0 |
50.3 |
42.9 |
42.0 |
47.3 |
39.7 |
39.0 |
|
20.0 |
48.8 |
40.7 |
39.5 |
45.8 |
37.7 |
36.5 |
|
25.0 |
47.3 |
38.8 |
36.9 |
44.3 |
35.8 |
33.9 |
|
31.25 |
45.9 |
36.9 |
34.2 |
42.9 |
33.9 |
31.2 |
|
62.5 |
41.4 |
30.8 |
24.4 |
38.4 |
27.8 |
21.4 |
|
100.0 |
38.3 |
26.8 |
16.3 |
35.3 |
23.8 |
13.3 |
|
155.0 |
35.5 |
22.9 |
7.4 |
32.5 |
19.9 |
4.4 |
|
200.0 |
33.8 |
20.7 |
1.4 |
30.8 |
17.7 |
NS |
|
300.0 |
32.3 |
17.2 |
NS |
28.2 |
14.2 |
NS |
|
350.0 |
30.2 |
15.9 |
NS |
27.2 |
12.9 |
NS |
