Pair 1 |
Blue/White w/Co-Extruded Blue Stripe on White Single |
|
Pair 2 |
Orange/White w/Co-Extruded Orange Stripe on White Single |
|
Pair 3 |
Green/White w/Co-Extruded Green Stripe on White Single |
|
Pair 4 |
Brown/White w/Co-Extruded Brown Stripe on White Single |
|
Frequency |
Impedance |
Return Loss |
Attenuation |
NEXT |
ELFEXT |
PS NEXT |
PS ELFEXT |
Delay Skew |
Propagation Speed |
|
MHz |
ohm |
≥dB |
≤dB |
≥dB |
≥dB |
≥dB |
≥dB |
ns |
≥m/s |
|
1 |
100+15 |
20 |
1.9 |
74.3 |
67.8 |
72.3 |
64.8 |
≤45 |
0.6c |
|
4 |
23 |
3.7 |
65.3 |
55.8 |
63.3 |
57.7 | |||
|
10 |
25 |
5.9 |
59.3 |
47.8 |
57.3 |
44.8 | |||
|
16 |
25 |
7.5 |
56.3 |
43.7 |
54.3 |
40.7 | |||
|
20 |
25 |
8.4 |
54.8 |
41.8 |
52.8 |
38.7 | |||
|
31.25 |
23.6 |
10.6 |
51.9 |
37.9 |
49.9 |
34.9 | |||
|
62.5 |
21.5 |
15.4 |
47.4 |
31.9 |
45.4 |
28.8 | |||
|
100 |
20.1 |
19.8 |
44.3 |
27.8 |
42.3 |
24.8 | |||
|
155 |
18.8 |
25.1 |
41.4 |
23.9 |
39.4 |
20.9 | |||
|
200 |
18 |
29 |
39.8 |
21.8 |
37.8 |
18.7 | |||
|
250 |
17.3 |
32.8 |
38.3 |
19.8 |
36.3 |
16.8 | |||
|
350 |
100+20 |
16.3 |
39.8 |
36.1 |
16.9 |
34.1 |
13.9 | ||
|
400 |
15.9 |
43 |
35.3 |
15.7 |
33.7 |
12.7 | |||
|
450 |
100+22 |
15.5 |
46.3 |
34.5 |
14.7 |
32.5 |
11.7 | ||
|
500 |
15.2 |
48.9 |
33.8 |
13.8 |
31.8 |
10.8 | |||
|
550 |
14.9 |
51.8 |
33.2 |
12.9 |
31.2 |
9.9 |
