Pair 1 |
Blue/White w/Co-Extruded Blue Stripe on White Single |
|
Pair 2 |
Orange/White w/Co-Extruded Orange Stripe on White Single |
|
Pair 3 |
Green/White w/Co-Extruded Green Stripe on White Single |
|
Pair 4 |
Brown/White w/Co-Extruded Brown Stripe on White Single |
|
Attenuation |
[@68℉. (20℃)] | ||
|
Frequency (MHz) |
Max. (dB/100 m) |
Frequency (MHz) |
Max. (dB/100 m) |
|
1.0 |
2.0 |
62.5 |
14.8 |
|
4.0 |
4.0 |
100.0 |
19.0 |
|
8.0 |
5.2 |
155.0 |
24.1 |
|
10.0 |
5.8 |
200.0 |
27.7 |
|
16.0 |
7.3 |
250.0 |
31.3 |
|
20.0 |
8.2 |
350.0 |
37.8 |
|
25.0 |
9.2 |
400.0 |
40.8 |
|
31.25 |
10.3 |
550.0 |
49.0 |
|
Return Loss |
[@68℉. (20℃)] | ||
|
Frequency (MHz) |
Min. (dB/100 m) |
Frequency (MHz) |
Min. (dB/100 m) |
|
1.0 |
23.0 |
62.5 |
23.5 |
|
4.0 |
23.6 |
100.0 |
23.0 |
|
8.0 |
25.4 |
155.0 |
21.6 |
|
10.0 |
26.0 |
200.0 |
21.0 |
|
16.0 |
26.0 |
250.0 |
18.3 |
|
20.0 |
26.0 |
350.0 |
17.3 |
|
25.0 |
25.5 |
400.0 |
16.9 |
|
31.25 |
25.0 |
550.0 |
15.9 |
|
Frequency
MHz |
Near to Cross Talk |
ACR
Min |
Power Sum Min. | ||
|
Min. |
NEXT |
ELFEXT |
ACR | ||
|
1.0 |
81.3 |
79.3 |
78.3 |
70.8 |
76.3 |
|
4.0 |
72.3 |
68.6 |
69.3 |
58.8 |
65.5 |
|
8.0 |
67.8 |
62.6 |
64.8 |
52.7 |
57.5 |
|
10.0 |
66.3 |
60.5 |
63.3 |
50.8 |
57.4 |
|
16.0 |
63.2 |
55.9 |
60.3 |
46.7 |
52.8 |
|
20.0 |
61.8 |
53.6 |
58.8 |
44.8 |
50.5 |
|
25.0 |
60.3 |
51.2 |
57.3 |
42.8 |
48.0 |
|
31.25 |
58.9 |
48.6 |
55.9 |
40.9 |
45.4 |
|
62.5 |
54.4 |
39.6 |
51.4 |
34.9 |
36.5 |
|
100.0 |
51.3 |
32.3 |
48.3 |
30.8 |
29.3 |
|
155.0 |
48.4 |
24.4 |
45.5 |
27.0 |
21.5 |
|
200.0 |
46.8 |
19.1 |
43.8 |
24.8 |
16.4 |
|
250.0 |
45.3 |
14.0 |
42.3 |
22.8 |
11.5 |
|
350.0 |
43.1 |
5.3 |
40.2 |
19.9 |
3.2 |
|
400.0 |
42.3 |
1.5 |
39.3 |
18.8 |
NA |
|
550.0 |
40.2 |
NA |
37.2 |
16.0 |
NA |
