BT2003 3002 RA7000 RA8000 TZC75024 4 Core

Other Products

1) Physical Dimensions

Component	Material	BT2003 4C	BT3002 4C	BTRA7000 4C	BTRA8000 4C	BT TZC75024 4C
Center Conductor	BC	0.574 mm	0.32 mm	0.6 mm	0.31 mm	0.32mm
Dielectric	PE	Solid PE	Solid PE	Foam PE	Cellular PE	Solid PE
First Shield		20X6X0.15mm TCX91%	16X6X0.16mm TCX91%	Al-PE Tape	Al-PE Tape	16X6X0.16mm XTCX91%
		24X6X0.15mm TCX90%	16X6X0.16mm TCX90%	TC Braid 95%	TC Braid 95%	16X6X0.16mm XTCX90%
Jacket	PVC	18.50 mm	10.20 mm	12.75 mm	8.25 mm	10.20mm

2) Attenuation

3) Electrical Characteristics:

Impedance: 75+3Ω

Capacitance: 53 pf/M

Velocity: 78%

Remark:

CCS=Copper Clad Steel

BC=Bare Copper

AL=Aluminium

☆ =No Option

※=As Per Your Option
