Component |
Material |
BT3002 16C |
BTRA7000 16C |
BTRA8000 16C |
BT TZC75024 16C |
|
Center Conductor |
BC |
0.32 mm |
0.6 mm |
0.31 mm |
0.32mm |
|
Dielectric |
PE |
Solid PE |
Foam PE |
Cellular PE |
Solid PE |
|
First Shield |
|
16X6X0.16mmTCX91% |
Al-PE Tape |
Al-PE Tape |
16X6X0.16mmXTCX91% |
|
Second Shield |
|
16X6X0.16mmTCX90% |
TC Braid 95% |
TC Braid 95% |
16X6X0.16mmXTCX90% |
|
Jacket |
PVC |
19.6 mm |
24.25 mm |
14.85 mm |
19.50mm |
|
Component |
BT3002 16C |
BTRA7000 16C |
BTRA8000 16C |
BT TZC75024 16C |
|
1 M Hz/100m |
2.13dB |
1.21dB |
1.89dB |
2.13dB |
|
4 M Hz/100m |
4.29dB |
2.50dB |
3.85dB |
4.29dB |
|
17 M Hz/100m |
8.93dB |
4.95dB |
8.02dB |
8.93dB |
|
69 M Hz/100m |
18.32dB |
9.15dB |
14.32dB |
18.32dB |
|
78 M Hz/100m |
19.53dB |
9.65dB |
16.53dB |
19.53dB |
