Physical Dimensions
|
|
|
|
|
|
|
|
Component |
Material |
100A |
195 |
200 |
240 |
300 |
|
Center Conductor |
BC mm |
0.4572 |
0.9398 |
1.1176 |
1.4224 |
1.778 |
|
Dielectric |
PE mm |
1.524 |
2.794 |
2.9464 |
3.81 |
4.826 |
|
First Shield |
Bonded AL Foil mm |
1.651 |
2.9464 |
3.0734 |
3.937 |
4.9784 |
|
Second Shield |
TC mm |
2.108 |
3.5306 |
3.6576 |
4.5212 |
5.715 |
|
Jacket |
PE mm |
2.794 |
4.953 |
4.953 |
5.334 |
7.62 |
|
Electrical Characteristics
|
|
|
|
|
|
|
|
Impedance |
ohm |
50 |
50 |
50 |
50 |
50 |
|
Velocity (%) |
|
66 |
80 |
83 |
84 |
85 |
|
Capacitance |
(pF per Foot) |
30.8 |
24.3 |
24.5 |
24.2 |
24.1 |
|
DC Resistance (ohms/1000’) |
center conductor |
81 |
7.58 |
5.36 |
3.2 |
2.12 |
|
|
shield |
9.5 |
4.9 |
4.9 |
3.89 |
2.21 |
|
Shielding |
dB |
>90 |
>90 |
>90 |
>90 |
>90 |
|
Attenuation ( dB per 100 feet ; +25C ) |
|
|
|
|
|
|
|
Frequency |
|
100A |
195 |
200 |
240 |
300 |
|
30 |
|
3.9 |
2.0 |
1.8 |
1.3 |
1.1 |
|
50 |
|
5.1 |
2.6 |
2.3 |
1.7 |
1.4 |
|
150 |
|
8.9 |
4.4 |
4.0 |
3.0 |
2.4 |
|
220 |
|
10.9 |
5.4 |
4.8 |
3.7 |
2.9 |
|
450 |
|
15.8 |
7.8 |
7.0 |
5.3 |
4.2 |
|
700 |
|
20.0 |
9.8 |
8.7 |
6.6 |
5.9 |
|
900 |
|
22.8 |
11.1 |
9.9 |
7.6 |
6.1 |
|
1500 |
|
30.0 |
14.5 |
12.9 |
9.9 |
7.9 |
|
2000 |
|
35.0 |
16.9 |
15.0 |
11.5 |
9.2 |
|
2500 |
|
40.0 |
19.0 |
16.9 |
12.9 |
10.4 |
|
5800 |
|
64.1 |
28.3 |
26.4 |
20.4 |
16.6 |
|
Physical Dimensions | ||||||||||
|
Component |
Material |
400 |
500 |
600 |
900 |
1200 |
1700 | |||
|
Center Conductor |
BC mm |
2.7686 |
3.6068 |
4.4704 |
6.6548 |
8.8646 |
13.3858 | |||
|
Dielectric |
Foam PE mm |
7.239 |
9.398 |
11.557 |
17.272 |
23.368 |
34.29 | |||
|
First Shield |
Bonded AL Foil mm |
7.3914 |
9.5504 |
11.709 |
17.4244 |
23.5204 |
34.4424 | |||
|
Second Shield |
TC mm |
8.128 |
10.287 |
12.446 |
18.5928 |
24.6888 |
35.6108 | |||
|
Jacket |
PE mm |
10.287 |
12.7 |
14.986 |
22.098 |
30.48 |
42.418 | |||
|
Electrical Characteristics | ||||||||||
|
Impedance |
ohm |
50 |
50 |
50 |
50 |
50 |
50 | |||
|
Velocity (%) |
|
85 |
86 |
87 |
87 |
88 |
89 | |||
|
Capacitance |
(pF per Foot) |
23.9 |
23.6 |
23.4 |
23.4 |
23.1 |
22.8 | |||
|
DC Resistance (ohms/1000’) |
center conductor |
1.39 |
0.82 |
0.53 |
0.54 |
0.32 |
0.21 | |||
|
|
shield |
1.65 |
1.27 |
1.2 |
0.55 |
0.37 |
0.27 | |||
|
Shielding |
dB |
>90 |
>90 |
>90 |
>90 |
>90 |
>90 | |||
|
Attenuation ( dB per 100 feet ; +25C ) | ||||||||||
|
Frequency |
|
400 |
500 |
600 |
900 |
1200 |
1700 | |||
|
30 |
|
0.7 |
0.54 |
0.421 |
0.288 |
0.209 |
0.149 | |||
|
50 |
|
0.9 |
0.70 |
0.547 |
0.374 |
0.272 |
0.195 | |||
|
150 |
|
1.5 |
1.22 |
0.964 |
0.658 |
0.481 |
0.347 | |||
|
220 |
|
1.8 |
1.49 |
1.18 |
0.803 |
0.589 |
0.427 | |||
|
450 |
|
2.7 |
2.17 |
1.72 |
1.17 |
0.864 |
0.632 | |||
|
700 |
|
3.42 |
2.77 |
2.18 |
1.48 |
1.10 |
0.809 | |||
|
900 |
|
3.9 |
3.13 |
2.50 |
1.70 |
1.27 |
0.936 | |||
|
1500 |
|
5.1 |
4.13 |
3.31 |
2.24 |
1.69 |
1.26 | |||
|
2000 |
|
6.0 |
4.84 |
3.90 |
2.63 |
1.99 |
1.50 | |||
|
2500 |
|
6.8 |
5.48 |
4.42 |
2.98 |
2.26 |
1.71 | |||
|
5800 |
|
10.8 |
8.90 |
7.30 |
4.90 |
|
| |||
