Item |
RG6 Quad |
UTP CAT 5E |
|
Center Conductor |
1.02+0.01mm CCS/BC |
0.51+0.01mm BC |
|
Dielectric/Insulation |
4.57+0.05mm Foam PE |
0.89+0.02mm PE |
|
Shield |
Bonded AL Foil 100% |
X |
|
Braid Coverage |
60%X64X0.16+0.005mm AL |
X |
|
Shield |
AL Foil 100% |
X |
|
Braid Coverage |
40%X48X0.16+0.005mm AL |
X |
|
Jacket |
7.54+0.05mm PVC |
5.08+0.05mm PVC |
|
JKT Spot Thickness |
0.61mm |
0.41mm |
|
Webb Thickness |
0.38mm | |
|
Overall Jacket |
7.5 to 13.80+0.05mm PVC | |
|
Pair 1 |
Blue/White w/Co-Extruded Blue Stripe on White Single |
|
Pair 2 |
Orange/White w/Co-Extruded Orange Stripe on White Single |
|
Pair 3 |
Green/White w/Co-Extruded Green Stripe on White Single |
|
Pair 4 |
Brown/White w/Co-Extruded Brown Stripe on White Single |
|
Item |
RG6 Quad |
UTP CAT 5E |
|
Impedance |
75+3Ω |
X |
|
Capacitance |
16.2 pF/ft |
14 pF/ft |
|
Velocity of Prop. |
85% |
PE =71% |
|
Conductor DCR |
9.3Ω/100m |
9.0Ω/100m |
|
SRL |
20dB (5-1000MHz)
15dB (1001-3000MHz) |
X |
|
Shield DCR |
3.2Ω/100m |
X |
|
Max Delay Skew |
X |
11 ns/100m |
|
Spark Test |
2500VAC |
2500VAC |
|
Attenuation |
[@68℉. (20℃)] | ||
|
Frequency (MHz) |
Max. (dB/100 ft) |
Frequency (MHz) |
Max. (dB/100 ft) |
|
1 |
0.37 |
900 |
5.79 |
|
5 |
0.55 |
1000 |
6.11 |
|
10 |
0.66 |
1200 |
6.73 |
|
50 |
1.41 |
1450 |
7.49 |
|
100 |
1.92 |
1800 |
8.43 |
|
200 |
2.64 |
2200 |
9.35 |
|
400 |
3.73 |
2500 |
9.97 |
|
700 |
5.05 |
3000 |
10.92 |
|
Frequency
MHz |
Attenuation
(dB/100m)
Max |
Pair to pair |
Return Los
(dB/100m)
Min |
ACR
(dB/100m)
Min |
Power Sum | |||
|
NEXT
(dB/100m)
Min |
ELFEXT
(dB/100m)
Min |
NEXT
(dB/100m)
Min |
ELFEXT
(dB/100m)
Min |
ACR
(dB/100m)
Min | ||||
|
0.772 |
1.8 |
70.0 |
69.0 |
NA |
68.2 |
67.0 |
66.0 |
65.0 |
|
1.0 |
2.0 |
68.3 |
66.8 |
20.0 |
66.3 |
65.3 |
63.8 |
63.3 |
|
4.0 |
4.0 |
59.3 |
54.7 |
23.0 |
55.2 |
56.3 |
51.7 |
52.2 |
|
8.0 |
5.8 |
54.8 |
48.7 |
24.5 |
49.0 |
51.8 |
45.7 |
47.0 |
|
10.0 |
6.5 |
53.3 |
46.8 |
25.0 |
46.8 |
50.3 |
43.8 |
43.8 |
|
16.0 |
8.2 |
50.3 |
42.9 |
25.0 |
42.0 |
47.3 |
39.7 |
39.0 |
|
20.0 |
9.2 |
48.8 |
40.7 |
25.0 |
39.5 |
45.8 |
37.7 |
36.5 |
|
25.0 |
10.4 |
47.3 |
38.8 |
24.3 |
36.9 |
44.3 |
35.8 |
33.9 |
|
31.25 |
11.7 |
45.9 |
36.9 |
23.6 |
34.2 |
42.9 |
33.9 |
31.2 |
|
62.5 |
17.0 |
41.4 |
30.8 |
21.5 |
24.4 |
38.4 |
27.8 |
21.4 |
|
100.0 |
22.0 |
38.3 |
26.8 |
20.1 |
16.3 |
35.3 |
23.8 |
13.3 |
|
155.0 |
28.1 |
35.5 |
22.9 |
18.8 |
7.4 |
32.5 |
19.9 |
4.4 |
|
200.0 |
32.4 |
33.8 |
20.7 |
18.0 |
1.4 |
30.8 |
17.7 |
NS |
|
300.0 |
41.0 |
32.3 |
17.2 |
16.8 |
NS |
28.2 |
14.2 |
NS |
|
350.0 |
44.9 |
30.2 |
15.9 |
16.3 |
NS |
27.2 |
12.9 |
NS |
|
Impedance |
1.0 – 100Mhz |
100 Ω+ 15% |
|
100 – 155Mhz |
100 Ω+ 18% | |
|
155 – 200Mhz |
100 Ω+ 19% | |
|
200 – 300Mhz |
100 Ω+ 22% | |
|
300 – 350Mhz |
100 Ω+ 24% |
